Quick Details

  • Condition: New
  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: QIANLI
  • Model Number: DHP3T
  • Usage: Construction Hoist
  • Power Source: Electric
  • Sling Type: Chain
  • Maximum Lifting Weight: 10T,or custom as your requirements
  • Maximum Lifting Height: 30M
  • Lift Speed: 3 M/min
  • Certification: CE /ISO9000
  • Warranty: 1year
  • After-sales Service Provided: Overseas third-party support available
  • Product name: electric construction chain hoisting machine in the philippines
  • Capacity: 3 t
  • Testing load: 3.75 t
  • Standard Lifting Height: 3 m,hoisting machine in the philippines
  • Lifting speed(m/min): 0.26/0.09 ,hoisting machine in the philippines
  • Motor power: 1.1 kw
  • Net Weight: 55kg
  • Min distance between hooks: 470mm
  • Power supply: 220V-440V,3phase,50/60HZ
  • control voltage can be customized: 24V/36V/48V

Packaging & Delivery

Packaging Details: carton or according to client's requirement,hoisting machine in the philippines
Delivery Detail: 7

Product Description

Introduction:

   DHP model chain electric hoist is the new product of our company. It is either easy to carry as the chain block or improve the disadvantage of manual operation and low lifting speed. It both has the davantage of compact structure, small volume, light weight, high effciency, easy to use and guard. It is suitable for low speed distant, loading and unloading materials, facilitating equipment, mineral and project erection. The products are with good quality and low price, safe and reliable. It will provide convenience to your work.


DHP Electric hoist Parameters

Rated load T

1T

2T

3T

5T

10T

20T

30T

Testing load T

1.25T

2.5T

3.75T

6.25T

12.5T

25T

37.5T

Lifting speed m/min

0.26/0.09

0.26/0.09

0.26/0.09

0.26/0.09

0.26/0.09

0.26/0.09

0.26/0.09

Loop track minimum Radius   mm

300

380

470

600

730

890

980

Standard lift m

3 M

Power

0.5KW

0.8KW

1.1KW

1.5KW

0.8KW

1.1KW

1.1KW

Frequency HZ

380V  50HZ

Weight

42Kg

50Kg

55Kg

62Kg

120Kg

230kg

310kg

Weight incrasing with each lifting height

0.82

1.7

2.9

4.42

8.84

17.84







Company Information




Packaging & Shipping




FAQ



1. Is your products customized?
Yes, because the working condition are different, all our products are customized depending on detail requirement! So if you give us more information about the lift capacity, span, lift height, power source and other specials, we will give you a very quick quote!



2. What’s the information should I provide when inquiry?
Thanks for your question. The more information you provide, the accurate solution we can prepare for you! The information such as the lift capacity, lift height, power source or other specials you give us will be more appreciated.



Our Services

   We TENGLI HENGXIN CRANE devote ourselves to providing the first rate and Proactive Service for our customer’s satisfaction.

Safety is priority among priorities for TENGLI HENGXIN CRANE. We provide professional Training and mentoring for our technicians, inspectors and your maintenance personnel and crane operators. We will customize and clearly defined training requirements for lifting equipment. We provide comprehensive support package designed to enhance the value of your workforce and improve safety awareness in the workplace.



Warranty:


1. 1 (one)year guarantee for main body.
2. we provide free maintenances for spare parts, but the new components replaced should be paid.
3. we arrange engineer to supervise installation, make the load test, do commissioning, train of the buyer's workers.
4. Delivery with English version user manual, parts manual, test certificates, class certificate and all other related documents.
5. Technique support: for any time, any way.
